MT47H128M16RT-25E IT:C

DRAM Chip DDR2 SDRAM 2G-Bit 128Mx16 1.8V 84-Pin FBGA T/R

EU RoHS: compliance

Part status: positive

DRAM type: DDR2 memory

Chip density (bit): 2G

Organization: 128Mx16

Number of internal banks: 8

Number of words per group: 16M

Number of digits/word (bits): 16

Data bus width (bits): 16

Maximum clock frequency (MHz): 800

Maximum access time (ns): 0.4

Process technology: CMOS

Interface type: SSTL_18

Minimum operating power supply voltage (V): 1.7

Typical working power supply voltage (V): 1.8

Maximum operating power supply voltage (V): 1.9

Working current (mA): 190

Minimum working temperature (°C): -40

Maximum working temperature (°C): 85

Number of I/O lines (bits): 16

Packing: tray

Standard package name: BGA

Number of pins: 84

Installation: surface mount
