There are many types of APW12 power supplies, and it is currently a widely used power supply, compatible with most models of the 19 series. This power supply includes a, b, c, d, e, and f versions. Among them, APW121215F is suitable for S19, S19pro, S19JPro, S19XP, S19JPro+ and other miners.
Brand new original, six months warranty, welcome to buy!
Before purchasing, please take the initiative to confirm the miner model and power supply version with the salesperson to ensure that the power supply can be used normally.
APW12
OUT1
DC Voltage
12V-15V
Rated Current(220 V input)
208A (when 15V can upto 233A~240A)
Ripple & Noise
<1%
Line Regulation
<1%
Load Regulation
<1%
Setup Time
<2S
Short Circuit Protection
>10mS
OUT2
DC Voltage
12.3V
Rated Current(220 V input)
15A
Ripple & Noise
<1%
Voltage Accuracy
12.2V---12.4V
Line Regulation
<1%
Load Regulation
<1%
Setup Time
<2S
Short Circuit Protection
>10mS
Input
Voltage Range
200-240V AC
Frequency Range
47-63Hz
Power Factor
>0.99(full load)
Leakage Current
<1.5mA（220V 50Hz）
Protection
Low-voltage Input
80-89V AC
Output Short Circuit
Yes
Overheat Protection
Yes
Over-current Output
291A-350A
(protection value varies under different voltage)
Environment
Operating Temperature
-20-45℃
Operating Humidity
20%-90%RH(non-condensing)
Altitude
< 2000m
Structure
Dimensions
254.6mm*251.6mm*63mm
Net Weight
3.6KG
Cooling System
forced‐air cooling
Noise
45dBA
